SVCS Horizontal Oxidation / Diffusion Furnace

Home > Facilities > Micro-/Nano Fabrication > Thermal Processing & Ion Implantation > Phosphorus Diffusion Furnace (N-Type Doping)

Equipment Information Guidelines for Contract Processing Inquiry

Phosphorus Diffusion Furnace (N-Type Doping)

Commissioning

Model：	AH3
Function：	High-temperature furnace tube for phosphorus diffusion doping processes.
Engineer：	Li / +86-21- 34206126-6015 / lijinxi@1
Location：	West Area – High-Temperature Furnace
Equipment ID：	WDFSOXD02

Reservation

Basic Equipment Information
Operating Principle
Typical Application Case

Main Applications

This furnace is used for phosphorus diffusion doping processes in semiconductor fabrication.

Process / Testing Capabilities

Phosphorus diffusion for 3", 4", and 6" silicon wafers. Process temperature: below 1100°C.

Technical Specifications

Atmospheric-pressure phosphorus diffusion furnace. Compatible with 3", 4", and 6" standard front-end clean silicon wafers. Doping achieved using a liquid phosphorus source (POCl₃, phosphorus oxychloride) at approximately 900°C.

At temperatures between 900°C and 1100°C, phosphorus oxychloride (POCl₃) is introduced into the furnace, where it reacts and diffuses phosphorus atoms into the wafer to achieve N-type doping.

344005be-335c-4ca0-8dc7-568abf0e1c60

Thermal diffusion doping in CMOS fabrication processes.

Front-end furnace only; contamination is strictly prohibited.

The list below shows FAQs (click a question to view the answer). If your question is not listed, you can leave a message using the link.

FAQs

01

Can this equipment be used for post-processed samples?

No. Contamination is strictly prohibited; post-processed samples are not allowed.
